| Head Studs: |
| TFX 9/16 NC (block) 9/16 or 1/2 (head) |
Top Row |
Bottom Row |
Top#1 |
| Stock - Deck Height 10.725 / stock Head Fuel or cast |
|
|
|
| .100 - Deck Height 10.825 / stock Head Fuel |
(9) 11.375 |
(16) 8.938 |
(1) 10.675 |
| Stock - Deck Height 10.725 / Thick Head (.100) Fuel |
(9) 11.375 |
(16) 8.938 |
|
| .100 - Deck Height 10.825 / Thick Head (.100) Fuel |
|
|
|
| Stock - Deck Height 10.725 / Fat Head |
|
|
|
| .100 - Deck Height 10.825 / Fat Head |
|
|
|
| -.500 - Deck Height 10.225 / Fat Head |
|
|
|
|
| BAE - Billet 9/16 NC (block) 9/16 or 1/2 (head) |
Top Row |
Bottom Row |
Top#1 |
| Stock - Deck Height 10.725 / stock Head Fuel or cast |
|
|
|
| .100 - Deck Height 10.825 / stock Head Height Fuel |
|
|
|
| Stock - Deck Height 10.725 / Thick Head (.100) Fuel |
|
|
|
| .100 - Deck Height 10.825 / Thick Head (.100) Fuel |
|
|
|
| Stock - Deck Height 10.725 / Fat Head |
(10) 8.85 |
(16) 7.20 |
? |
| .100 - Deck Height 10.825 / Fat Head |
|
|
|
| -.500 - Deck Height 10.225 / Fat Head |
|
|
|
|
| KB - Stage xxxx 9/16 NC (block) 9/16 or 1/2 (head) |
Top Row |
Bottom Row |
Top#1 |
| Stock - Deck Height 10.725 /stock Head Fuel or cast |
|
|
|
| .100 - Deck Height 10.825 / stock Head Height Fuel |
|
|
|
| Stock - Deck Height 10.725 / Thick Head (.100) Fuel |
|
|
|
| .100 - Deck Height 10.825 / Thick Head (.100) Fuel |
|
|
|
| Stock - Deck Height 10.725 / Fat Head |
|
|
|
| .100 - Deck Height 10.825 / Fat Head |
|
|
|
| -.500 - Deck Height 10.225 / Fat Head |
|
|
|
|
| KB - Stage 3 - 5 1/2 NC (block) 1/2 NF (head) |
Top Row |
Bottom Row |
Top#1 |
| Stock - Deck Height 10.725 / stock Head Fuel or cast |
12.125 |
10.85 |
10.375 |
| " " 9/16NC (block) |
12.3 - 12.5 |
11 |
10.4 |
| .100 - Deck Height 10.825 / stock Head Height Fuel |
|
|
|
| Stock - Deck Height 10.725 / Fat Head |
(10) 8.85 |
(16) 7.20 |
? |
| .100 - Deck Height 10.825 / Fat Head |
|
|
|
| -.500 - Deck Height 10.225 / Fat Head |
|
|
|
|
| Valley |
- Inner Head Stud 7/16-20" x 7/16-14"
| |
length |
| Stock - Deck Height 10.725 |
3.750" newer blocks TFX-2000+ = 4.25" |
| .100 - Deck Height 10.825 |
3.750" + |
| -.500 - Deck Height 10.225 |
3.00" |
|
| Torque: |
KB : stage 3-5 std (1/2) head studs: ARP oil or Anti - Seize
| |
Cast Iron |
Alum |
Veney (billet) |
| Top row |
85 |
85 |
90 |
| Bottom row |
80 |
80 |
85 |
| Valley |
45 |
40 |
45 |
------------------------------------------------------------------------------------------------------------- |
| Solid Blocks: |
| Torque in circles from outside -> in (1974 specs ) |
Veney Billet Fuel Thick heads -- KB high strength / Billet Blocks 9/16 HS studs:
Top 165, bottom 130, valley 75 Torque in circles from outside -> in |
| H11 - Tool steel are higher ?? 185 --- 160 |
 |
| |
 |
| |
 |
| Re torque Info ? |
 |
